SA6 Technical Specifications

Product model SA6
OS Android 14
Processor Octa-Core 2.0GHz
GPU Quad-core Mali-G52 2EE Supports OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 Built-in high-performance 2D acceleration hardware
NPU 1 TOPS
Memory 2GB RAM+32GB ROM Supports USB expansion
Wi-Fi Wi-Fi, dual-band, Support 2.4G/5G Support 4G network(※)
Ethernet 10M/100M/1000M
Bluetooth Bluetooth4.2
Multimedia Supports 4K@60fps H.265/H.264/VP9 video decoding Supports 1080P@60fps H.265/H.264 video encoding Supports 8M ISP, supports HDR
Display Ports 1 HDMI port, HDMI Type-A, max supports 4K@60Hz (output)
Peripheral Ports 2*TYPE-A USB3.0 , 1*TYPE-A USB2.0 port, 1*M2 (KEY M) port 2*RS485 , 2*RS232 , 2*CAN, 6*GPIO 1*Line Out port, 1*3.5mm headphone jack 1*NANO-SIM card slot, 1*red/green indicator light, 1*infrared signal input
Power DC 12V
Operation Environment Working temperature: -20℃~40℃ Operation humidity: 30%-80%
Storage Environment Storage temperature: -25℃~70℃ Storage humidity: 30%-80%
Dimensions 136mm(L)*124.4mm(W)*32mm(H)

※ Optional: This symbol indicates that the corresponding feature, component, or service is optional and not included in the standard product configuration.

1. In case of any discrepancy between the actual usage data and the above data, the actual usage data shall prevail.
2. The product information on this page may be updated periodically due to product upgrades or other reasons. SUNTEK reserves the right to modify the product information and content on this website without prior notice.
